Playing with Shifter Part 2 – converted Docker containers inside Slurm

This is continuing on from my previous blog about NERSC’s Shifter which lets you safely use Docker containers in an HPC environment.

Getting Shifter to work in Slurm is pretty easy, it includes a plugin that you must install and tell Slurm about. My test config was just:

required /usr/lib64/shifter/shifter_slurm.so shifter_config=/etc/shifter/udiRoot.conf

as I was installing by building RPMs (out preferred method is to install the plugin into our shared filesystem for the cluster so we don’t need to have it in the RAM disk of our diskless nodes). One that is done you can add the shifter programs arguments to your Slurm batch script and then just call shifter inside it to run a process, for instance:

#!/bin/bash

#SBATCH -p debug
#SBATCH --image=debian:wheezy

shifter cat /etc/issue

results in the following on our RHEL compute nodes:

[samuel@bruce Shifter]$ cat slurm-1734069.out
Debian GNU/Linux 7 \n \l

simply demonstrating that it works. The advantage of using the plugin and this way of specifying the images is that the plugin will prep the container for us at the start of the batch job and keep it around until it ends so you can keep running commands in your script inside the container without the overhead of having to create/destroy it each time. If you need to run something in a different image you just pass the --image option to shifter and then it will need to set up & tear down that container, but the one you specified for your batch job is still there.

That’s great for single CPU jobs, but what about parallel applications? Well turns out that’s easy too – you just request the configuration you need and slap srun in front of the shifter command. You can even run MPI applications this way successfully. I grabbed the dispel4py/docker.openmpi Docker container with shifterimg pull dispel4py/docker.openmpi and tried its Python version of the MPI hello world program:

#!/bin/bash
#SBATCH -p debug
#SBATCH --image=dispel4py/docker.openmpi
#SBATCH --ntasks=3
#SBATCH --tasks-per-node=1

shifter cat /etc/issue

srun shifter python /home/tutorial/mpi4py_benchmarks/helloworld.py

This prints the MPI rank to demonstrate that the MPI wire up was successful and I forced it to run the tasks on separate nodes and print the hostnames to show it’s communicating over a network, not via shared memory on the same node. But the output bemused me a little:

[samuel@bruce Python]$ cat slurm-1734135.out
Ubuntu 14.04.4 LTS \n \l

libibverbs: Warning: couldn't open config directory '/etc/libibverbs.d'.
libibverbs: Warning: no userspace device-specific driver found for /sys/class/infiniband_verbs/uverbs0
--------------------------------------------------------------------------
[[30199,2],0]: A high-performance Open MPI point-to-point messaging module
was unable to find any relevant network interfaces:

Module: OpenFabrics (openib)
  Host: bruce001

Another transport will be used instead, although this may result in
lower performance.
--------------------------------------------------------------------------
libibverbs: Warning: couldn't open config directory '/etc/libibverbs.d'.
libibverbs: Warning: couldn't open config directory '/etc/libibverbs.d'.
Hello, World! I am process 0 of 3 on bruce001.
libibverbs: Warning: no userspace device-specific driver found for /sys/class/infiniband_verbs/uverbs0
--------------------------------------------------------------------------
[[30199,2],1]: A high-performance Open MPI point-to-point messaging module
was unable to find any relevant network interfaces:

Module: OpenFabrics (openib)
  Host: bruce002

Another transport will be used instead, although this may result in
lower performance.
--------------------------------------------------------------------------
Hello, World! I am process 1 of 3 on bruce002.
libibverbs: Warning: no userspace device-specific driver found for /sys/class/infiniband_verbs/uverbs0
--------------------------------------------------------------------------
[[30199,2],2]: A high-performance Open MPI point-to-point messaging module
was unable to find any relevant network interfaces:

Module: OpenFabrics (openib)
  Host: bruce003

Another transport will be used instead, although this may result in
lower performance.
--------------------------------------------------------------------------
Hello, World! I am process 2 of 3 on bruce003.

It successfully demonstrates that it is using an Ubuntu container on 3 nodes, but the warnings are triggered because Open-MPI in Ubuntu is built with Infiniband support and it is detecting the presence of the IB cards on the host nodes. This is because Shifter is (as designed) exposing the systems /sys directory to the container. The problem is that this container doesn’t include the Mellanox user-space library needed to make use of the IB cards and so you get warnings that they aren’t working and that it will fall back to a different mechanism (in this case TCP/IP over gigabit Ethernet).

Open-MPI allows you to specify what transports to use, so adding one line to my batch script:

export OMPI_MCA_btl=tcp,self,sm

cleans up the output a lot:

Ubuntu 14.04.4 LTS \n \l

Hello, World! I am process 0 of 3 on bruce001.
Hello, World! I am process 2 of 3 on bruce003.
Hello, World! I am process 1 of 3 on bruce002.

This also begs the question then – what does this do for latency? The image contains a Python version of the OSU latency testing program which uses different message sizes between 2 MPI ranks to provide a histogram of performance. Running this over TCP/IP is trivial with the dispel4py/docker.openmpi container, but of course it’s lacking the Mellanox library I need and as the whole point of Shifter is security I can’t get root access inside the container to install the package. Fortunately the author of the dispel4py/docker.openmpi has their implementation published on Github and so I forked their repo, signed up for Docker and pushed a version which simply adds the libmlx4-1 package I needed.

Running the test over TCP/IP is simply a matter of submitting this batch script which forces it onto 2 separate nodes:

#!/bin/bash
#SBATCH -p debug
#SBATCH --image=chrissamuel/docker.openmpi:latest
#SBATCH --ntasks=2
#SBATCH --tasks-per-node=1

export OMPI_MCA_btl=tcp,self,sm

srun shifter python /home/tutorial/mpi4py_benchmarks/osu_latency.py

giving these latency results:

[samuel@bruce MPI]$ cat slurm-1734137.out
# MPI Latency Test
# Size [B]        Latency [us]
0                        16.19
1                        16.47
2                        16.48
4                        16.55
8                        16.61
16                       16.65
32                       16.80
64                       17.19
128                      17.90
256                      19.28
512                      22.04
1024                     27.36
2048                     64.47
4096                    117.28
8192                    120.06
16384                   145.21
32768                   215.76
65536                   465.22
131072                  926.08
262144                 1509.51
524288                 2563.54
1048576                5081.11
2097152                9604.10
4194304               18651.98

To run that same test over Infiniband I just modified the export in the batch script to force it to use IB (and thus fail if it couldn’t talk between the two nodes):

#!/bin/bash
#SBATCH -p debug
#SBATCH --image=chrissamuel/docker.openmpi:latest
#SBATCH --ntasks=2
#SBATCH --tasks-per-node=1

export OMPI_MCA_btl=openib,self,sm

srun shifter python /home/tutorial/mpi4py_benchmarks/osu_latency.py

which then gave these latency numbers:

[samuel@bruce MPI]$ cat slurm-1734138.out
# MPI Latency Test
# Size [B]        Latency [us]
0                         2.52
1                         2.71
2                         2.72
4                         2.72
8                         2.74
16                        2.76
32                        2.73
64                        2.90
128                       4.03
256                       4.23
512                       4.53
1024                      5.11
2048                      6.30
4096                      7.29
8192                      9.43
16384                    19.73
32768                    29.15
65536                    49.08
131072                   75.19
262144                  123.94
524288                  218.21
1048576                 565.15
2097152                 811.88
4194304                1619.22

So you can see that’s basically an order of magnitude improvement in latency using Infiniband compared to TCP/IP over gigabit Ethernet (which is what you’d expect).

Because there’s no virtualisation going on here there is no extra penalty to pay when doing this, no need to configure any fancy device pass through, no loss of any CPU MSR access, and so I’d argue that Shifter makes Docker containers way more useful for HPC than virtualisation or even Docker itself for the majority of use cases.

Am I excited about Shifter – yup! The potential to allow users build and application stack themselves right down to the OS libraries and (with a little careful thought) having something that could get native interconnect performance is fantastic. Throw in the complexities of dealing with conflicting dependencies between Python modules, system libraries, bioinformatics tools, etc, etc, and needing to provide simple methods for handling these and the advantages seem clear.

So the plan is to roll this out into production at VLSCI in the near future. Fingers crossed! 🙂

Playing with Shifter – NERSC’s tool to use Docker containers in HPC

Early days yet, but playing with NERSC’s Shifter to let us use Docker containers safely on our test RHEL6 cluster is looking really interesting (given you can’t use Docker itself under RHEL6, and if you could the security concerns would cancel it out anyway).

To use a pre-built Ubuntu Xenial image, for instance, you tell it to pull the image:

[samuel@bruce ~]$ shifterimg pull ubuntu:16.04

There’s a number of steps it goes through, first retrieving the container from the Docker Hub:

2016-08-01T18:19:57 Pulling Image: docker:ubuntu:16.04, status: PULLING

Then disarming the Docker container by removing any setuid/setgid bits, etc, and repacking as a Shifter image:

2016-08-01T18:20:41 Pulling Image: docker:ubuntu:16.04, status: CONVERSION

…and then it’s ready to go:

2016-08-01T18:21:04 Pulling Image: docker:ubuntu:16.04, status: READY

Using the image from the command line is pretty easy:

[samuel@bruce ~]$ cat /etc/lsb-release
LSB_VERSION=base-4.0-amd64:base-4.0-noarch:core-4.0-amd64:core-4.0-noarch:graphics-4.0-amd64:graphics-4.0-noarch:printing-4.0-amd64:printing-4.0-noarch

[samuel@bruce ~]$ shifter --image=ubuntu:16.04 cat /etc/lsb-release
DISTRIB_ID=Ubuntu
DISTRIB_RELEASE=16.04
DISTRIB_CODENAME=xenial
DISTRIB_DESCRIPTION="Ubuntu 16.04 LTS"

and the shifter runtime will copy in a site specified /etc/passwd, /etc/group and /etc/nsswitch.conf files so that you can do user/group lookups easily, as well as map in site specified filesystems, so your home directory is just where it would normally be on the cluster.

[samuel@bruce ~]$ shifter --image=debian:wheezy bash --login
samuel@bruce:~$ pwd
/vlsci/VLSCI/samuel

I’ve not yet got to the point of configuring the Slurm plugin so you can queue up a Slurm job that will execute inside a Docker container, but very promising so far!

Correction: a misconception on my part – Shifter doesn’t put a Slurm batch job inside the container. It could, but there are good reasons why it’s better to leave that to the user (soon to be documented on the Shifter wiki page for Slurm integration).

Mount Burnett Observatory Open Day – 23rd February 2016 – noon until late!

If you’re around Melbourne, interested in astronomy and fancy visiting a community powered astronomical observatory that has a very active outreach and amateur astronomy focus then can I interest you in the Mount Burnett Observatory open day this Saturday (January 23rd) from noon onwards?

MBO Open Day flyer image

We’re going to have all sorts of things going on – talks, telescopes, radio astronomy, tours of the observatory dome (originally built by Monash University), lots of enthusiastic volunteers!

We’re fundraising to build a new accessible modern dome to complement the existing facilities so please come and help us out.

Let’s Encrypt – getting your own (free) SSL certificates

For those who’ve not been paying attention the Let’s Encrypt project entered public beta recently so that anyone could get their own SSL certificates. So I jumped right in with the simp_le client (as the standard client tries to configure Apache for you, and I didn’t want that as my config is pretty custom) and used this tutorial as inspiration.

My server is running Debian Squeeze LTS (for long painful reasons that I won’t go into here now) but the client installation was painless, I just patched out a warning about Python 2.6 no longer being supported in venv/lib/python2.6/site-packages/cryptography/__init__.py. 🙂

It worked well until I got rate limited for creating more than 10 certificates in a day (yeah, I host a number of domains).

Very happy with the outcome, A+ would buy again.. 🙂

Git: Renaming/swapping “master” with a branch on Github

I was playing around with some code and after having got it working I thought I’d make just one more little quick easy change to finish it off and found that I was descending a spiral of additional complexity due to the environment in which it had to work. As this was going to be “easy” I’d been pushing the commits to master on Github (I’m the only one using this code) and of course a few reworks in I’d realised that this was never going to work out well and needed to be abandoned.

So, how to fix this? The ideal situation would be to just disappear all the commits after the last good one, but that’s not really an option, so what I wanted was to create a branch from the last good point and then swap master and that branch over. Googling pointed me to some possibilities, including this “deprecated feedback” item from “githubtraining” which was a useful guide so I thought I should blog what worked for me in case it helps others.

  1. git checkout -b good $LAST_GOOD_COMMIT # This creates a new branch from the last good commit
  2. git branch -m master development # This renames the "master" branch to "development"
  3. git branch -m good master # This renames the "good" branch to "master".
  4. git push origin development # This pushes the "development" branch to Github
  5. In the Github web interface I went to my repos “Settings” on the right hand side (just above the “clone URL” part) and changed the default branch to “development“.
  6. git push origin :master # This deletes the "master" branch on Github
  7. git push --all # This pushes our new master branch (and everything else) to Github
  8. In the Github web interface I went and changed my default branch back to “master“.

…and that was it, not too bad!

You probably don’t want to do this if anyone else is using this repo though. 😉

Thoughts on the white spots of Ceres

If you’ve been paying attention to the world of planetary exploration you’ll have noticed the excitement about the unexpected white spots on the dwarf planet Ceres. Here’s an image from May 29th that shows them well.

Ceres with white spots

Having looked at a few images my theory is that impacts are exposing some much higher albedo material, which you can see here at the top of the rebound peak at the center of the crater, and that the impact has thrown some of this material up and that material has fallen back as Ceres has rotated slowly beneath it giving rise to the blobs to the side of the crater.

If my theory is right then if you know Ceres gravity and its rotational speed and the distance between the rebound peak and the other spots then you should be able to work out how far up the material was thrown up. That might tell you something about the size of the impact (depending on how much you know about the structure of Ceres itself).

As an analogy, here’s an impact on Mars captured by the HiRise camera on MRO that shows an area of ice exposed by an impact.

UniFi systemd unit file for Ubuntu 15.04

At work we’ve started using some UniFi wireless gear and the system I’ve managed to commandeer to do the control system for it is running Kubuntu 15.04 which uses systemd. Now the UniFi Debian packages don’t supply systemd unit files so I went hunting and found a blog post by Derek Horn about getting it running on CentOS7 so I nabbed his and adapted it for Ubuntu (which wasn’t that hard).

The file lives in /etc/systemd/system/unifi.service and was enabled with systemctl enable unifi.service (from memory, there might have been another step that involved getting systemd to rescan unit files to pick up the new one, but I don’t remember for sure).

Here is the unit file:

#
# Systemd unit file for unifi-rapid
#

[Unit]
Description=UniFi Wireless AP Control System
After=rsyslog.target network.target

[Service]
Type=simple
User=root
#ExecStart=/usr/bin/java -Xmx1024M -jar /usr/lib/unifi/lib/ace.jar start
ExecStart=/usr/bin/jsvc -nodetach -home /usr/lib/jvm/java-7-openjdk-amd64 -cp /usr/share/java/commons-daemon.jar:/usr/lib/unifi/lib/ace.jar -pidfile /var/run/unifi/unifi.pid -procname unifi -outfile SYSLOG -errfile SYSLOG -Djava.awt.headless=true -Dfile.encoding=UTF-8 -Xmx1024M com.ubnt.ace.Launcher start
#ExecStop=/usr/bin/java -jar /usr/lib/unifi/lib/ace.jar stop
ExecStop=/usr/bin/jsvc -home /usr/lib/jvm/java-7-openjdk-amd64 -cp /usr/share/java/commons-daemon.jar:/usr/lib/unifi/lib/ace.jar -pidfile /var/run/unifi/unifi.pid -procname unifi -outfile SYSLOG -errfile SYSLOG -Djava.awt.headless=true -Dfile.encoding=UTF-8 -Xmx1024M -stop com.ubnt.ace.Launcher stop
SuccessStartStatus=0
SuccessExitStatus=255

[Install]
WantedBy=multi-user.target
